Super Capacitor 24volt

Designed to offer superior performance and efficiency, the 24 Volt Super Capacitor is a revolutionary energy storage solution. With its high capacitance and rapid charging capabilities, it provides an ideal alternative to traditional batteries in various applications. Whether it is in renewable energy systems, electric vehicles, or power backup systems, our super capacitor ensures reliable and long-lasting power supply. Built with utmost precision and quality materials, this product embodies our commitment to excellence

  • Rapid Charging: Fully charges in seconds to minutes, providing instant power availability.
  • Reliable power backup: designed for high reliability scenes, quickly switches to super capacitor discharge during power loss.
  • Endurance and data save provides 10-60 seconds of power down endurance, ideal for on site data storage.
  • Voltage Balancing: When building with smaller modules, active or passive balancing is necessary to keep individual cell voltages below their rating.
  • Isolation: Use Schottky diodes to prevent back-feeding into the power source.
  • Intuitive indicator light power indicator displays connection status and capacitor voltage, ensuring visibility.
  • Long Life: Maintenance-free with a lifespan often exceeding 5 years.
  • Output Consistency: Many units convert the 24V buffer to a stable output.
  • Efficient input and output accepts 24Volt DC input, after input supply off delivers 13.5volt max 1A current.

Technical Specification

  • Power Input range : 24Volt DC
  • Power Output: 24Volt DC after input supply off 13.5 Volt DC
  • Super Capacitor: 15F x 3
  • Charging Current: charging pick current 2.5Amp 5sec. normal 1.3Amp.for 3min to fully charge capacitor.
  • Discharge Current: 24Volt 3A (continuous) when connected to external power supply, 13.5Volt 3A (within 10s full current) when only super capacitor output.
  • Power Indication: V cap green led light brightness changes with capacitor voltage. Brightest when capacitor is full, off when capacitor is discharged
  • Product Size: Compact and practical design compact and lightweight with a approx 72x41x25mm size, easy to connect and use.
